MORTAR GONIOMETER GP1M

This GP1M enables daytime and nighttime sighting of an artillery system in both elevation and azimuth. This single plate goniometer is meant to ensure high precision laying on fixed landscape marks. Its compact size and robust design enable it to remain attached to the mortar throughout the firing sequence.


Applications


Designed for mortars up to 120mm and artillery guns up to 155mm, it is a simpler version of the double-plate GP2M in wide use in the French army, built to the same standards of excellence and robustness.


Features and benefits


Endurance: field qualified for over 2500 shots of 120mm mortar rounds

The scope’s focus is set to infinity and it features an engraved reticle, graduated every 5 mrad on the horizontal axis, and “thin and thick” vertical line to improve both accuracy and low-light readability.

The sighting goniometer is mounted directly on the mortar's dovetail mount. For applications other than mortars, contact us for compatibility or adaptation.

Scrome Military sights LTE

Scrome Military aligning sights

Accessories


• Instruction Manual

• UV filter on removable mount

• Slipcover

• Replacement sunshade

• Handheld flashlight for nighttime use (stored inside the goniometer’s body)
